Brookeld Engineering Labs., Inc. Page 115 Manual No. M13-167-A0415

Appendix I - Laboratory Stands

ModelGisthestandardlaboratorystandwhichcomeswiththeDV3TRheometer.

Item PartNo. Description Qty

1 VS-CRA-14S UprightRodandClampAssembly 1

VS-CRA-18S UprightRodandClampAssembly Optional

2 GV-1201 Base,includes2GV-1203levelingscrews 1

3 GV-1203 LevelingScrewsavailableseparatelyorinassemblyabove 2

4 502028071S33B FlatWasher5/16X7/8X.071 1

5 50S311832S01B Screw,5/16-18X1”HexHead 1

Figure I-1: Model G Laboratory Stand
