Brookfield DV3T User Manual

Brookeld Engineering Labs., Inc. Page 103 Manual No. M13-167-A0415
Appendix E - Spindle Entry Codes and Range Coecients
The range coefcient is a convenient tool for quickly determining the maximum viscosity
that can be measured with a specic spindle/speed combination. Identify the spindle in
use and the torque range (LV, RV, HA, HB) of the Viscometer/Rheometer. Look up the
Range Coefcient in the following table. Divide the Range Coefcient by the spindle
speed to determine the maximum viscosity in centipoise that can be measured.
E.g. RV Viscometer with RV3 spindle: Range Coefcient is 100,000. At 50 RPM, the
maximum viscosity that can be measured is 100,000/50 or 2,000 cP.
The Entry Code is the two digit number used to identify the spindle in use when operating
a standard digital Viscometer/Rheometer.
Table E-1
(Continued on following page)
Spindle Entry Code
Range Coefcient
LV RV HA HB
RV1
01 937
10,000 20,000 80,000
RV2
02 3,750
40,000 80,000 320,000
RV3
03 9,375
100,000 200,000 800,000
RV4
04 18,750
200,000 400,000 1,600,000
RV5
05 37,500
400,000 800,000 3,200,000
RV6
06 93,750
1,000,000 2,000,000 8,000,000
RV7
07 375,000
4,000,000 8,000,000 32,000,000
HA1
01 937
10,000 20,000 80,000
HA2
02 3,750
40,000 80,000 320,000
HA3
03 9,375
100,000 200,000 800,000
HA4
04 18,750
200,000 400,000 1,600,000
HA5
05 3,7500
400,000 800,000 3,200,000
HA6
06 93,750
1,000,000 2,000,000 8,000,000
HA7
07 375,000
4,000,000 8,000,000 32,000,000
HB1
01 937
10,000 20,000 80,000
HB2
02 3,750
40,000 80,000 320,000
HB3
03 9,375
100,000 200,000 800,000
HB4
04 18,750
200,000 400,000 1,600,000
HB5 05
37,500
400,000 800,000 3,200,000
HB6
06 93,750
1,000,000 2,000,000 8,000,000
HB7
07 375,000
4,000,000 8,000,000 32,000,000
LV1
61 6,000
64,000 128,000 512,000
LV2
62 30,000
320,000 640,000 2,560,000
LV3
63 120,000
1,280,000 2,560,000 10,240,000
LV4 or 4B2
64 600,000
6,400,000 12,800,000 51,200,000
LV5
65 1,200,000
12,800,000 25,600,000 102,400,000
LV-2C
66 30,000
320,000 640,000 2,560,000
LV-3C
67 120,000
1,280,000 2,560,000 10,240,000
