Brookfield DV3T User Manual

Brookeld Engineering Labs., Inc. Page 104 Manual No. M13-167-A0415
Spindle Entry Code
Range Coefcient
LV RV HA HB
T-A
91 18,750
200,000 400,000 1,600,000
T-B
92 37,440
400,000 800,000 3,200,000
T-C
93 9,3600
1,000,000 2,000,000 8,000,000
T-D
94 187,200
2,000,000 4,000,000 16,000,000
T-E
95 468,000
5,000,000 10,000,000 40,000,000
T-F
96 936,000
10,000,000 20,000,000 80,000,000
Spiral
70 98,400
1,050,000 2,100,000 8,400,000
ULA
00 600
6,400 12,800 51,200
HT-DIN-81
81 3,420
36,500 73,000 292,000
SC4-DIN-82
82 3,420
36,500 73,000 292,000
SC4-DIN-83
83 11,340
121,300 242,600 970,400
ULA-DIN-85
85 1,144
12,200 24,400 97,600
ULA-DIN-86
86 3,420
36,500 73,000 292,000
ULA-DIN-87
87 11,340
121,300 242,600 970,400
SC4-14/6R
14 117,200
1,250,000 2,500,000 10,000,000
SC4-15/7R
15 46,880
500,000 1,000,000 4,000,000
SC4-16/8R
16 120,000
1,280,000 2,560,000 10,240,000
SC4-18/13R
18 3,000
32,000 64,000 256,000
SC4-21/13R
21 4,688
50,000 100,000 400,000
SC4-25/13R
25 480,000
5,120,000 10,240,000 40,960,000
SC4-27/13R
27 23,440
250,000 500,000 2,000,000
SC4-28/13R
28 46,880
500,000 1,000,000 4,000,000
SC4-29/13R
29 93,750
1,000,000 2,000,000 8,000,000
SC4-31/13R
31 30,000
320,000 640,000 2,560,000
SC4-34/13R
34 60,000
640,000 1,280,000 5,120,000
CPA-40, CPE-40, CP-40
40 307
3,270 6,540 26,160
CPA-41, CPE-41, CP-41
41 1,151
12,280 24,560 98,240
CPA-42, CPE-42, CP-42
42 600
6,400 12,800 51,200
CPA-51, CPE-51, CP-51
51 4,854
51,780 103,560 414,240
CPA-52, CPE-52, CP-52
52 9,300
99,220 198,440 793,760
V-71
71 2,456
26,200 52,400 209,600
V-72
72 10,404
111,000 222,000 888,000
V-73
73 50,146
535,000 1,070,000 4,280,000
V-74
74 508,954
5,430,000 10,860,000 43,440,000
V-75
75 199,645
2,130,000 4,260,000 8,520,000
Table E-1
(Continued on previous page)
