Brookfield DV3T - III.7 Selecting Data Collection

Brookeld Engineering Labs., Inc. Page 32 Manual No. M13-167-A0415
allowforamorecompletecharacterizationofauidandmayhelpinformulationandproduction
ofaproduct.TheDV3Tiscapableofcollectingmultipledatapointsforcomprehensiveanalysis
ofowbehavior.
Moreinformationonowbehavior,shearrateandrheogramsisavailableinourpublication,“More
SolutionstoStickyProblems”.
III.7 Selecting Data Collection
TheDV3TRheometeroffersseveraloptionsfordatacollection.TheDataCollectionsettingis
showninCongureViscosityTestdirectlyundertheTemperaturedisplay.Thefactorysettingis
SinglePoint(seeFigureIII-8).Pressingthebluearrow,inthiseld,willpresenttheDataCollection
screen(seeFigureIII-9).
Figure III-8 Figure III-9
Single Point:CollectonlyasingledatapointwhentheEndConditionismet.
Single Point Averaging:Specifyanamountoftimeoverwhichtoaveragemeasureddata.
CollectasingledatapointwhentheEndConditionismet.This
datapointisanaveragedvalue.Ifthetimeforaveragingisshorter
thanthetotaltimeforthestep,thentheaveragewillbeperformed
forthespeciedtimeattheendofthetest.
  Example1:TheEndConditionisTimewithavalueof1minuteand30seconds,theSingle
PointAveragingDurationis30seconds,thesingledatapointcollectedfromthis
stepwillbeanaverageofthedatameasuredfrom1minuteto1minute30seconds.
Multi Point:Collect multiple datapointsbased on time.TheData Interval isspeciedin
Hours:Mins:Secs.IftheEndConditionissettoTime,thenthetotalnumberof
