ElectricalCertications:
ConformstoCEStandards:
BSEN61326: Electricalequipmentformeasurement,controlandlaboratoryuse-EMC
requirements.
BSEN61010-1: Safetyrequirementsforelectricalequipment,formeasurement,control
andlaboratoryuse.
 AirborneNoiseEmissions-levelsdonotexceed70dB(A).
Notice to customers:
Thissymbolindicatesthatthisproductistoberecycledatanappropriatecollectioncenter.
Users within the European Union:
Pleasecontactyourdealerorthelocalauthoritiesinchargeofwastemanagementonhowtodispose
ofthisproductproperly.AllBrookeldofcesandournetworkofrepresentativesanddealerscan
befoundonourwebsite:www.brookeldengineering.com.
Users outside of the European Union:
Pleasedisposeofthisproductaccordingtoyourlocallaws.
I.4 Installation
Note:“IQ,OQ,PQ”,anabbreviatedguidelinedocumentforinstallation,operationand
performancevalidationforyourDV3Tdigitalrheometer,canbedownloadedfrom
ourwebsitewww.brookeldengineering.com.AmoredetailedIQ,OQ,PQprocedure
isavailableforpurchasefromBrookeldoryourauthorizeddealer.
1. AssembletheModelGLaboratoryStand(refertoassemblyinstructionsinAppendixI).
2. Puttherheometeronthestand.
3. ConnecttheRTDprobetothesocketontherearpaneloftheDV3T.
4. Therheometermustbeleveled.Thelevelisadjustedusingthetwolevelingscrewson
thebase.AdjustsothatthebubblelevelonthefrontoftheDV3T iscenteredwithinthe
circle.
Note: Checklevelperiodicallyduringuse.
5. Removetheshippingcapwhichsecuresthecouplingnutontherheometertothepivot
cup.ForCone/PlateModels,holdtheSampleCupandswingthetensionbaraway
fromthebottomofthecup.Lowerthecupandremovethefoaminsert.(Saveforfuture
shipments.)
6. Optional:Installthescreenprotectorpertheinstructionsonthepackage(andalso
showninAppendixK).Failuretoproperlyinstallthescreenprotectormayresult
intouchscreenmalfunction.Additionalinstallationhelpcanalsobefoundonour
YouTubechannel:www.youtube.com/user/BrookfieldEng
TheACinputvoltageandfrequencymustbewithintheappropriaterangeasshown
onthenameplateoftheviscometer(seeSectionI.2)
