Brookeld Engineering Labs., Inc. Page 101 Manual No. M13-167-A0415
SPINDLE ENTRY CODE SMC SRC
T-A 91 20 0
T-B 92 40 0
T-C 93 100 0
T-D 94 200 0
T-E 95 500 0
T-F 96 1000 0
ULA 00 0.64 1.223
DIN-81 81 3.7 1.29
DIN-82 82 3.75 1.29
DIN-83 83 12.09 1.29
DIN-85 85 1.22 1.29
DIN-86 86 3.65 1.29
DIN-87 87 12.13 1.29
SC4-14 14 125 0.4
SC4-15 15 50 0.48
SC4-16 16 128 0.29
SC4-18 18 3.2 1.32
SC4-21 21 5 0.93
SC4-25 25 512 0.22
SC4-27 27 25 0.34
SC4-28 28 50 0.28
SC4-29 29 100 0.25
SC4-31 31 32 0.34
SC4-34 34 64 0.28
CP-40, CPE-40 or CPA-40Z 40 0.327 7.5
CP-41, CPE-41 or CPA-41Z 41 1.228 2
CP-42, CPE-42 or CPA-42Z 42 0.64 3.84
CP-51, CPE-51 or CPA-51Z 51 5.178 3.84
CP-52, CPE-52 or CPA-52Z 52 9.922 2
SPINDLE ENTRY CODE SMC SRC YMC
V-71 71 2.62 0 0.5
V-72 72 11.1 0 2
V-73 73 53.5 0 10
V-74 74 543 0 100
V-75 75 213 0 40
Table D-1
(continued from previous page)
