Table:Displayalldatapoints.Datawillbeshowninascrolllistwhereeachpagecanholda
maximumof50points.Ifthedatasethasmorethan50points,thenadditionalpages
willbeindicatedatthebottomofthescreen.Additionalpagesofdatacanbeaccessed
throughtheuseoftheBlueArrows
Eachdatapointincludes:Viscosity,Torque,Speed,Temperature,Time,ShearStress
(SS),ShearRate(SR),Density,andAccuracy.
Test Used:Displaythetestelementsusedtogeneratethedataset.Inthisview,theCongure
Testbuttonisavailable.SelectingCongureTestwillprogramtheDV3Ttorun
thesametestutilizedtocollectthedatasetbeingviewedandpresenttheCongure
ViscosityTestscreen.
Notes:Documentanyrelevantinformationaboutthetestordata.Thisinformationwillbe
storedwiththedatasetoncesaved.
Compare Results:Loadtwodatasetsandviewsidebyside(seeFigureIV-9).
Device Info:DisplaybasicinformationaboutthedataleandthespecicDV3TRheometer
usedtocollectthedataincluding:dateandtimetheteststarted,completedand
wassaved;ifuseraccountsareactive,whichusersavedthedata;rheometerserial
number,rmwareversion,rheometerTorquerange(LV,RV,HA,HB,other).
Graph:Displaythenaldatapointandgraph(seeFigureIV-10).Thegraphaxis(XandY)
canbechangedbyselectingthebluedropdownarrowintheappropriatedataeld.
ZoomandresetcontrolsareindicatedundertheX-Axis.
Figure IV-10Figure IV-9
