Disassembly
2 - 4
Disassembly
Disassembly
Main frame / Covers / Upper thread guide
2
Clothplate cover assy
1. Remove the screw (screw, bind M4x6) and the screw (screw, bind M4x16) to remove the clothplate
cover assy.
Fig. 2-2
Screw, Bind M4X6
Screw, Bind M4X16
Cothplate cover assy
Screw, bind M4x16
Screw, bind M4x6
