Disassembly
2 - 52
Disassembly
Disassembly
Needle bar
2
Needle bar driving lever assy
1. Remove the two screws (screw, bind M4x16) to remove the needle bar driving lever assy.
Fig. 2-3
Screw, Bind M4X16
Screw, bind M4x16
Screw, bind M4x16
Needle bar driving
lever assy
Needle bar driving
lever assy
