1 - 2
Outline of Mechanism
Outline of
Mechanism
Outline of
Mechanism
Main mechanisms
Main body
Thread tension mechanism
Looper mechanism
Feed mechanism
Upper blade & Lower blade mechanism
Driving shaft mechanism
Presser foot mechanism
Needle bar mechanism
