Brother CS8000 Series User Manual

3 - 49
Needle-presser module
Modules
Assembly
1
Shaft bushing assembly attachment
1. Attach the shaft bushing assy. 1 to the upper unit holder using screws 1
(two).
Start movie clip (CD-ROM version only)
1
Torque
1.18 – 1.57 N
−m
1
1
Set Screw, Sock
e
M3X5
Color; Bl
a
2
Thread take-up lever link assembly
1. Attach the shaft 1, spring Aand thread take-up lever link 2 to the
upper unit holder, and attach retaining ring E4.
2. Install screw 1 in the shaft 1.
Start movie clip (CD-ROM version only)
Apply Molykote EM 30L grease all the way around
the shaft hole in the thread take-up lever link.
Small amount
1
Torque
0.49 N
−m
S06
1
Retaining ring E4
11
S06
S06
Set Screw, Socket (CP
)
M3X5
Color; Black
5.2
20.7
SPRING
XC2441***
