5 - 26
Failure Investigation
for Electronic Parts
Failure Investigation for Electronic Parts Error is displayed
Connect the SSVR PCB assy.
to CN2 (S2) or CN1 (S3) on the
operate PCB assy. correctly
Is the SSVR PCB assy. correctly
connected to CN2 (S2) or CN1
(S3) on the operate PCB assy.?
N
Y
Replace SSVR PCB assy.
"F7 (S2) or F07 (S3)" is displayed
S2 : CS8000 Series
S3 : CS8100 Series
