Brother CS8000 Series User Manual

2 - 6
Main parts
Main unit
8
Handle removal
1. Remove the screws 1 (two), and detach the handle and the handle fixed
plates 1 (two) and handle 2 from the arm bed.
1
12
9
Base cover B assy. removal
1. Remove the screws 1 (two), and remove the base cover B assy. 1 from
the arm bed.
1 1
10
Base cover B assy. disassembly
1. Remove the screw 1, and remove base cover B 2 from base plate B 1.
2. Remove the adjusting screw 3 and base plate rubber from base plate B 1.
2
113
