Brother CS8000 Series User Manual

2 - 32
Thread tension mechanism
Main unit
14
Tension disk removal
1. Remove the tension control nut assy. 1, spring , washer, tension disc
washer, thread release plate A, washer, tension disk B and tension disk A.
2. Remove the tension adjusting screw 2 from the tension control nut assy.
1.
3. Remove the thread tension shaft 3 and the spring cover shaft 4.
2
S28
3
1
1
4
S28
