Feed module
Modules
Disassembly
5
FPM spring removal
1. Remove the spring .
S16
S16
6
F pulse motor assy. removal
1. Remove screw 1 and screw 2, and remove spring and the F pulse
motor assy.
Start movie clip (CD-ROM version only)
S15
21
S15
7
F pulse motor disassembly
1. Remove screws 1 (two), and remove the F pulse motor (FPMSMJ35-
4840-C) 1.
2. Remove the rubber from the FPM holder assy. 2.
Start movie clip (CD-ROM version only)
1 2
1
8
Inner rotary hook bracket assy. removal
1. Remove screw 1, and remove the inner rotary hook bracket assy. 1.
