3 - 25
Upper shaft mechanism
Main unit
Assembly
14
Bobbin winder assy. attachment
1. Attach a washer 1 and the bobbin winder assy. 2 to the arm bed using
screw 1.
1
Torque
0.57 - 0.78 N-m
1
12
Giza Tite
4X12
Color; Gold
