3-12
Confidential
5 Toner LED PCB ASSY/Main fan
6 Laser unit
Harness colors may be changed for any reason.
Toner LED
PCB ASSY
Hook
Toner LED harness (RD, BL, WH)
Hooks
Main fan harness (RD, WH)
Main fan
Hook
Laser unit flat cable
Core
Laser unit
HooksToner LED harness (RD, BL, WH)
