1.3.9 Display LAN connection status (function code: 33)
<Function>
This function is to check the connection status of the wired LAN.
<Operation Procedure>
(1) Press the [ ] or [ ] button in the initial state of maintenance mode to display
"Maintenance 33" on the LCD.
(2) Press the [OK] button. The wired LAN connection status as shown in the table below is
displayed on the LCD.
(3) Pressing the [ ] or [ ] button changes the display item.
(4) When the [Cancel] button is pressed, the machine returns to the initial state of
maintenance mode.
LCD Wired LAN connection status
Active 1000B-FD 1000B-FD
Active 1000B-HD 1000B-HD
Active 100B-FD 100B-FD
Active 100B-HD 100B-HD
Active 10B-FD 10B-FD
Active 10B-HD 10B-HD
Inactive Not connected
