3-74
Confidential
(3) Remove the earth registration spring from the hook on the feed chute, and remove the
earth registration spring from the feed chute.
(4) Remove the electrode TR from the hook on the registration actuator holder ASSY, and
remove the electrode TR from the registration actuator holder ASSY.
(5) Release the hook, and remove the registration actuator holder ASSY from the feed
chute.
Fig. 3-75
Hook
Earth registration spring
Registration actuator holder ASSY
Hook
Electrode TR
Feed chute
Hook
