Brother HL-5440D Service Manual

1-2
Confidential
Specifications are subject to change without notice.
Specifications are subject to change without notice.
Model
HL-5440D HL-5450DN HL-5450DNT HL-5470DW HL-5470DWT
Noise level Sound
pressure
Printing LpAm = 59 dB (A)
Printing
(Quiet
Mode)
LpAm = 54 dB (A)
Ready LpAm = 34 dB (A)
Sound
power
Printing LWAd = 6.79 B (A)
Printing
(Quiet
Mode)
LWAd = 6.4 B (A)
Ready LWAd = 4.70 B (A) LWAd =
4.63 B (A)
LWAd =
4.70 B (A)
LWAd =
4.63 B (A)
Environment Temperature
Operating: 10 to 32.5°C
Storage: 0 to 40°C
Humidity Operating: 20 to 80%
Storage: 10 to 90% (without condensation)
Dimensions
(W x D x H)
Carton Size 499 x 478 x 380 mm
(19.6 x 18.8 x 15.0 inch)
664 x 503 x
671 mm
(26.1 x 19.8
x 26.4 inch)
499 x 478 x
380 mm
(19.6 x 18.8
x 15.0 inch)
664 x 503 x
671 mm
(26.1 x 19.8
x 26.4 inch)
Machine Size 371 x 384 x 245 mm
(14.6 x 15.1 x 9.6 inch)
371 x 384 x
375 mm
(14.6 x 15.1
x 14.8 inch)
371 x 384 x
257 mm
(14.6 x 15.1
x 10.1 inch)
371 x 384 x
387 mm
(14.6 x 15.1
x 15.2 inch)
Weights Without Carton,
With toner/drum
10.4 kg /
22.9 lb
10.5 kg /
23.1 lb
13.6 kg /
29.9 lb
10.5 kg /
23.1 lb
13.6 kg /
30.4 lb
LCD Size
N/A 1.87 x 0.20 inch
(16 characters x 1 line)
Model HL-6180DW HL-6180DWT
Print method Electrophotographic Laser Printer
Resolution
1200 x 1200 dpi, HQ1200 (2400 x 600 dpi) quality, 600 x 600 dpi
Print speed One-sided Up to 40/42 ppm (A4/Letter size)
Two-sided 18/18 sides per minute (9/9 sheets per minute) (A4/Letter size)
Warm-up
time
From Sleep
mode
Less than 1 second at 73.4F / 50% (23°C / 50%)
From Power
OFF → ON
Less than 25 seconds at 73.4F / 50% (23°C / 50%)
First print
time
From Ready
mode
Less than 8.5 seconds at 73.4F (23°C) / 115V or 230V
From Sleep
mode
Less than 10 seconds at 73.4F (23°C) / 115V or 230V
CPU StarSapphire 400 MHz
Memory Standard 128 MB
Option Up to 256 MB (DDR2 16 bit, 144 pin)

Brother HL-5440D Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Processor family	Star Sapphire
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.4 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.7 W
Package weight	11.800 g
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
