Brother HL-5440D Service Manual

5-60
Confidential
 Adjust left-end print start position on second side when duplex printing (LCD
model only)
<Function>
In the event that the left-end print start position deviates on the second side when duplex
printing, use this function to adjust the position left and right.
The adjustable range is -100 to 750 (unit: 300 dpi). (Shifted to left when the value is negative)
<Operation Procedure>
(1) While the machine is in the ready state, press the [Go] and [ ] buttons simultaneously.
"USBNo." is displayed on the LCD.
(2) Press the [ ] or [ ] button to display "DX.XAdjust" on the LCD.
(3) Press the [OK] button. "DX.XAdjust=**" is displayed on the LCD.
(The value currently set is displayed for **.)
(4) To shift the writing start position to the left, press the [ ] button to decrease the value.
To shift the position to the right, press the [ ] button to increase the value.
(5) Press the [OK] button. "Accepted" is displayed on the LCD, and the machine returns to
the ready state.
 Change ON/OFF setting for Deep Sleep function when Deep Sleep function is
enabled and machine has Storage Data (Secure) (LCD model only)
<Function>
When the machine has the Storage Data (Secure) available, use this function to set whether
to permit the machine to enter Deep Sleep mode. This function is effective when the Deep
Sleep function is enabled (ON).
The setting currently selected is marked "*" at the end of the display.
<Operation Procedure>
(1) While the machine is in the ready state, press the [Go] and [ ] buttons simultaneously.
"USBNo." is displayed on the LCD.
(2) Press the [ ] or [ ] button to display "DpSlp.StrDt" on the LCD.
(3) Press the [OK] button. "DpSlp.StrDt=ON" is displayed on the LCD.
(4) Display "DpSlp.StrDt=ON" on the LCD when permitting the machine to enter Deep Sleep
mode, or "DpSlp.StrDt=OFF" when not permitting it.
(5) Press the [OK] button. "Accepted" is displayed on the LCD, and the machine returns to
the ready state.
LCD Description
DpSlp.StrDt = ON The Deep Sleep function is activated even when the machine
has Storage Data (Secure) available. (Default)
DpSlp.StrDt = OFF The Deep Sleep function is not activated when the machine
has Storage Data (Secure) available.

Brother HL-5440D Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Processor family	Star Sapphire
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.4 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.7 W
Package weight	11.800 g
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
