Brother HL-5440D Service Manual

2-44
Confidential
 Error code 8C00
The registration front sensor does not detect paper pass within the specified time after the
paper was picked up from the MP tray.
 Error code 8D00
When the power switch was turned ON, the eject sensor detected paper pass or detected
that the fuser cover was open.
 Error codes 8E00 and 8F00
These errors do not usually occur during normal use. The possible causes are noise around
the installation site, fluctuation of the power supply voltage, and failures in the software.
An unidentified error occurred.
Jam MP Tray
<User Check>
• Remove the paper jammed in the MP tray.
Step Cause Remedy
1 Foreign object in the MP tray Remove the foreign object.
2
Registration front actuator caught
in some sections of the machine
Reattach the registration front actuator.
3
Connection failure of the
registration front/rear sensor
harness
Check the connection of the registration front/
rear sensor PCB harness, and reconnect it if
necessary.
4
Abrasion of the MP paper pick-
up roller
Replace the MP paper feeding kit.
5
Registration front sensor failure
Refer to "1.3.8 Check sensor operation (function
code: 32)" in Chapter 5 to check the sensor
operation. If the sensor operation is faulty, replace
the registration front/rear sensor PCB ASSY.
6 Main PCB failure Replace the main PCB ASSY.
Cover is Open
<User Check>
• Close the fuser cover.
• Remove the paper jammed in the fuser cover.
Step Cause Remedy
1
Eject actuator caught in some
sections of the machine
Reattach the eject actuator.
2 Eject actuator failure Replace the fuser cover.
3
Eject sensor failure Refer to "1.3.8 Check sensor operation
(function code: 32)" in Chapter 5 to check the
sensor operation. If the sensor operation is
faulty, replace the eject sensor PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
---
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.

Brother HL-5440D Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Processor family	Star Sapphire
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.4 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.7 W
Package weight	11.800 g
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
