1.3.9 Display LAN connection status (Function code 33)
< Function >
This function is used to check the connection status of the wired LAN.
< Operating Procedure >
(1) For models with touch panel
Press the [3] twice in the initial state of maintenance mode.
For models without touch panel
Press the [▲] or [▼] in the initial state of maintenance mode to display
“MAINTENANCE 33” on the LCD, and press the [OK].
(2) One of the items in the following table is displayed on the LCD depending on the wired
LAN connection of the machine.
(3) Press the [X] or [Cancel], and the machine returns to the initial state of maintenance
mode.
LCD LAN connection status
Active 100B-FD 100B-FD
Active 100B-HD 100B-HD
Active 10B-FD 10B-FD
Active 10B-HD 10B-HD
Inactive Not connected
