Brother HL-L3210CW - Page 42

2-23
Confidential
Drum ! Slide the Green tab
on Drum Unit.
Electric discharge that may be
caused by dirt on the corona
wire of the drum unit was
detected.
6A00 2-66
Slide the Green tab
on Drum Unit.
Black(BK)
Electrified terminal or GRID
terminal signal detected that the
black drum was not installed
when the machine was turned
ON.
620A 2-62
Slide the Green tab
on Drum Unit.
Cyan(C)
Electrified terminal or GRID
terminal signal detected that the
cyan drum was not installed
when the machine was turned
ON.
620D 2-62
Slide the Green tab
on Drum Unit.
Magenta(M)
Electrified terminal or GRID
terminal signal detected that the
magenta drum was not installed
when the machine was turned
ON.
620C 2-62
Slide the Green tab
on Drum Unit.
Yellow(Y).
Electrified terminal or GRID
terminal signal detected that the
yellow drum was not installed
when the machine was turned
ON.
620B 2-62
Drum End
Soon:BK
-
Number of the black drum unit
rotations reaches the upper limit
soon.
4001 2-57
Drum End
Soon:C
-
Number of the cyan drum unit
rotations reaches the upper limit
soon.
4004 2-57
Drum End
Soon:M
-
Number of the magenta drum
unit rotations reaches the upper
limit soon.
4003 2-57
Drum End
Soon:Y
-
Number of the yellow drum unit
rotations reaches the upper limit
soon.
4002 2-57
Error message
Description
Error
codes
Refer
to:
First line Second line
