2-74
Confidential
■ Error code 9801
An error occurred with the value measured during color density adjustment performed from
the control panel.
<User Check>
• Check if the toner cartridges are set in the correct order of colors.
• Replace the toner cartridge.
• Replace the drum unit.
• If the belt unit has a scratch, replace it.
• If “WT Box End Soon” is displayed on the LCD and the belt unit has dirt, replace the waste
toner box.
■ Error code 9802
Dot counter or develop roller counter of color toner has reached the upper limit during color
density adjustment performed from the control panel.
<User Check>
• Replace the corresponding toner cartridge.
Step Cause Remedy
1
Dirt on the registration mark
sensor L
Clean the registration mark sensor L.
2
Failure in printed measurement If failure occurs when printing “K/W/Y/M/
C” in “Function code 71”, refer to “4.3
Troubleshooting for Image Defects” in this
chapter and take a measure.
3
Connection failure of the
registration mark sensor L
harness
Reconnect the registration mark sensor L
harness.
4
Density sensor failure Replace the registration mark sensor L
PCB.
5 Main PCB failure Replace the main PCB.
Step Cause Remedy
1 Main PCB failure Replace the main PCB.
To Next Page
