Brother MFC-8880DN - Paper Feed Chute ASSY

5-77
Confidential
9.8.19 Paper Feed Chute ASSY
(1) Remove the two cup S M3x8 Taptite screws.
(2) Remove the Paper feed plate. (For the models with the DX only)
Fig. 5-66
(3) Remove the two cup S M3x8 Taptite screws.
(4) Remove the Paper feed chute ASSY.
Fig. 5-67
Taptite cup S M3x8
Taptite cup S M3x8
Paper feed plate
Taptite cup S M3x8
Taptite cup S M3x8
Paper feed chute ASSY
