Brother MFC-8880DN Service Manual

7-41
Confidential
4.21 Display of the Machine’s Log Information (Function code 80)
<Function>
The machine may display its log information on the LCD.
<Operating Procedure>
(1) Press the [8] and [0] keys in this order in the initial stage of the maintenance mode. The
USB serial number appears on the LCD.
(2) Press the [Start] button. Each time the [Start] button is pressed, one of the following
information items appears on the LCD. The representative items are given below.
(3) Press the [Stop/Exit] button so that the machine stops this operation, beeps for one
second and returns to the initial stage of the maintenance mode.
*1 When you press the [OK] button while the MACHINE ERR error code is displayed,
the last error code is displayed. Each time the [OK] button is pressed, up to the ten
error codes are displayed one by one in reverse order.
*2 When you press the [OK] button while the COMEER1 error is displayed, the last
error, the previous error, and the second previous error are displayed in turn. The
indication changes from COMEER1, COMEER2, to COMEER3.
USB: Serial number
DRUM: Drum count
DRUM_PG Number of printed pages with the drum unit.
DRUM_CH Number of times the drum unit has been replaced.
KTN_PG1: Number of printed pages with the Black toner cartridge.
KTN_PG2:
Previous number of printed pages with the Black toner cartridge.
KTN_CH: Number of times the Black toner cartridge has been replaced.
WTNR_PG: Number of printed pages with the waste toner box. *
1
WTNR_CH: Number of times the waste toner box has been replaced. *
1
BELT_PG: Number of printed pages with the belt unit. *
1
BELT_CH: Number of times the belt unit has been replaced. *
1
PFMP_PG: Number of Printed pages with the MP paper feeding kit.
PFMP_CH: Number of times the MP paper feeding kit has been replaced.
PFK1_PG: Number of Printed pages with the T1 paper feeding kit.
PFK1_CH: Number of times the T1 paper feeding kit has been replaced.
PFK2_PG: Number of printed pages with the LT paper feeding kit.
PFK2_CH: Number of times the LT paper feeding kit has been replaced.
FUSR_PG: Number of printed pages with the fuser unit.
FUSR_CH: Number of times the fuser unit has been replaced.
LASR_PG: Number of printed pages with the laser unit.
LASR_CH: Number of times the laser unit has been replaced.
KCVRGUSI: Coverage with the toner cartridge. (%) *
2
KCVRGACC: Cumulative coverage (%) *
2
TTL_PG: Total number of printed pages
TTLCOPY: Number of copies made
TTLPCPT: Number of PC prints made

Brother MFC-8880DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16
Time to first copy (black, normal)	10.5 s
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Business
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Print, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	Scan
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (PowerSave)	18 W
Power consumption (average operating)	680 W
Maximum duty cycle	- pages per month
Package weight	22100 g
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Ultimate, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
