Brother MFC-8880DN - Eject Roller B4

5-93
Confidential
9.8.36 Eject Roller B4
(1) Remove the four Eject rollers B4 and two Pressure roller shaft S from the Document
cover.
Fig. 5-95
Assembling Note:
• When assembling the Eject rollers B4, ensure that the direction of each roller is
correct as shown in the figure above.
Eject rollers B4
Eject rollers B4
Pressure roller shaft S
Hook
<Front side>
Pressure roller shaft S
Document cover
