4.9 ROM Version Check (Function code 25)
<Function>
This function allows you to check the management information of the software programs
such as version information, check sum.
<Operating Procedure>
(1) Press the [2] key and [5] key in this order in the initial stage of the maintenance mode.
The machine displays each of terms described below on the LCD.
(2) Press the [ ] or [ ] button to check the next term.
*1 I-FAX firmware version does not display on the LCD, if you have not downloaded the
I-FAX.
*2 In the case of the model without Demo data, the “D·········· : ····” displayed on the LCD.
*3 To perform the ROM Check Sum, press the [OK] button during the "ROM Check
Sum" is displayed on the LCD. If the calculation result of the check sum is correct,
"ROM Check Sum OK" will be displayed on the LCD, otherwise "ROM Check Sum
NG" will be displayed on the LCD.
• How to display the check sum information
Terms displayed with “*” have the check sum information as well. Press the [OK]
button when its version information is displayed on the LCD. Press the [OK] button
again to go back to the version information display. Press the [ ] or [ ] buttons to
check the next term.
(3) To terminate this operation, press the [Stop/Exit] button. The machine beeps for one
second and returns to the initial stage of the maintenance mode.
LCD Description
TOTAL: Ver A* Main firmware version information (Revision information)
PCL : Ver1.00* Sub firmware (PCL/PS) version information (ROM size)
NET : Ver1.00 Network version information
PANEL : A08103015 Panel firmware version information
i0802312359: 1234*
*1
I-FAX firmware version information
B0808071049:5708* Boot program creation date & check sum information
U0812271600:7B0A* Main firmware creation date & check sum information
D0812312359: 1234*
*2
Demo program creation date & check sum information
P0812271602:BD40* Sub firmware (PCL/PS) creation date & check sum information
ROM Check Sum
*3
Calculate the check sum information of the main and PCL and
display the “OK” if right.
Note:
• Even if you press the [OK] button when each version information of Engine,
Network and Panel is displayed on the LCD, you cannot check the check sum
information.

Brother MFC-8880DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16
Time to first copy (black, normal)	10.5 s
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Business
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Print, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	Scan
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (PowerSave)	18 W
Power consumption (average operating)	680 W
Maximum duty cycle	- pages per month
Package weight	22100 g
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Ultimate, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
