Brother MFC-8880DN Service Manual

7-36
Confidential
4.17 Paper Feeding and Ejecting Test (Function code 67)
<Function>
This function allows you to check that a sheet of paper is fed and ejected correctly by printing
the grid pattern on a page, whose interval is 1cm.
<Operating Procedure>
(1) Press the [6] and [7] keys in this order in the initial stage of the maintenance mode.
(2) The “SLECT A4” will appear on the LCD. Select the paper size by using [ ] [ ] button.
Press the [OK] button.
(3) The “SELECT: TRAY1” will appear on the LCD. Select the paper tray by using [ ] [ ]
button. Press the [OK] button.
(4) The “PAPER DEED TEST” will appear on the LCD. The test printing is started, and the
grid pattern is printed.
(5) Press the [Stop/Exit] button so that machine stops printing. Then the machine returns to
the initial stage of the maintenance mode.
4.18 EEPROM Customizing (Function code 74)
<Function>
This function allows you to customize the EEPROM according to language, function settings,
and worker switch settings.
<Operating Procedure>
(1) Press the [7] and [4] keys in this order in the initial stage of the maintenance mode.
The current customizing code appears.
(2) Enter the desired customizing code (e.g., MFC-8890DW (US): 0401). The newly entered
code appears.
To enter letters “A” through “F”, press the [1] through [6] keys while holding down the [#]
key respectively.
(3) Press the [Start] button.
The machine saves the setting and displays the “PARAMETER INIT” on the LCD. The
machine beeps for one second and returns to the initial stage of the maintenance mode.
If you press the [Stop/Exit] button or no buttons are pressed for one minute in the above
procedure, the machine stops the procedure, beeps for one second and returns to the
initial stage of the maintenance mode.
The modification of the setting data is not saved in this case.
Note:
• In the case that the front cover is opened, or that there is no paper in the tray during
test printing, the test printing is stopped.
Note:
• If you replace the main PCB, be sure to carry out this procedure.
Note:
• The machine does not work properly when an incorrect code is entered.

Brother MFC-8880DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16
Time to first copy (black, normal)	10.5 s
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Business
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Print, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	Scan
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (PowerSave)	18 W
Power consumption (average operating)	680 W
Maximum duty cycle	- pages per month
Package weight	22100 g
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Ultimate, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
