Brother MFC-8880DN Service Manual

3-6
Confidential
Document Jam The document was not
inserted or fed properly, or
the document scanned
from the ADF was too
long.
Remove the jammed paper from the
ADF.
3-29
DR Mode in Use The machine is set to
Distinctive Ring mode. You
cannot change the
Receive Mode from
Manual to another mode.
Set Distinctive Ring to Off.
-
Drum Error The corona wire on the
drum unit needs to be
cleaned.
Clean the corona wire on the drum
unit.
3-21
3-23
The drum unit has reached
the end of its life.
Replace the drum unit.
Duplex Disabled The duplex tray is not
installed properly.
Remove the duplex tray and install it
again.
3-16
Fuser Error The temperature of fuser
unit does not rise at a
specified temperature
within specified time.
Do one of the following:
Turn the power switch off, wait a few
seconds, and then turn it on again.
Leave the machine for 15 minutes
with the power on.
3-17
3-19
3-20
3-21
3-38
The fuser unit is too hot.
Init Unable XX The machine has a
mechanical problem.
Perform processing with the error
code.
-
Jam Duplex The paper is jammed in
the duplex tray.
Remove the jammed paper from the
duplex tray.
3-16
Jam Rear The paper is jammed in
the back of the machine.
Remove the jammed paper from the
back of the machine.
3-24
Jam Inside The paper is jammed
inside the machine.
Remove the jammed paper from the
inside of the machine.
3-25
Jam MP Tray The paper is jammed in
the MP tray of the
machine.
Remove the jammed paper from the
MP tray. 3-26
Jam Tray 1
Jam Tray 2
The paper is jammed in
the paper tray of the
machine.
Remove the jammed paper from the
tray 1 or 2. 3-26
No Paper The machine is out of
paper or paper is not
properly loaded in the
paper tray.
Do one of the following:
Refill the paper in the paper tray or
MP tray.
Remove the paper and load it again.
3-28
No Response/
Busy
The number you dialed
does not answer or is busy.
Verify the number and try again. 3-73
3-74
No Toner The toner cartridge or the
drum unit and toner
cartridge assembly is not
installed properly.
Re-install the toner cartridge or the
drum unit and toner cartridge
assembly.
3-14
No Tray The paper tray is not
completely closed.
Close the paper tray properly.
3-24
Error Message Type of Error Action
Refer
to

Brother MFC-8880DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16
Time to first copy (black, normal)	10.5 s
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Business
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Print, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	Scan
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (PowerSave)	18 W
Power consumption (average operating)	680 W
Maximum duty cycle	- pages per month
Package weight	22100 g
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Ultimate, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
