BRAVO Analyzer - User Manual Bruker Optik GmbH
Operation 4
4.11 Mounting / demounting the carrying strap
4.11.1 General information
BRAVO is delivered with the carrying strap not being mounted. The carrying strap can
be mounted on either side of the BRAVO analyzer.
i
We recommend the usage of the carrying strap. It facilitates carrying and holding the
BRAVO analyzer and provides for a more secure hold of the BRAVO analyzer.
The delivery scope includes the following items:
4.11.2 Procedure
1x carrying strap
2x mounting elements
2x slotted pan head screws ((M2x6)
1x flat tip screwdriver
1. Remove the two covering caps ①
using the flat tip screwdriver.
