BRAVO Analyzer - User Manual
Specification A
A.5 WiFi module
The BRAVO analyzer is equipped with a WiFi module which supports the standards
IEEE 802.11b/g/n.
This WiFi module has an approval certificate for the U.S. and Canada.
A.6 Barcode reader
A.6.1 Depth of field range
A.6.2 Resolution
approval certificate for the U.S. FCC ID: 2AD88-BRAVO-01
approval certificate for Canada IC: 5969A-TIWI101
Symbology Depth of field - Typical range
100% U.P.C. 46 mm to 419 mm (1.8’’ to 16.5’’)
5 mil Code 39 64 mm to 163 mm (2.5’’ to 6.4’’)
10 mil Code 39 28 mm to 338 mm (1.1’’ to 13.3’’)
6.7 mil PDF417 46 mm to 185 mm (1.8’’ to 7.3’’)
10 mil Data Matrix 53 mm to 203 mm (2.1’’ to 8.0’’)
Type of barcode Resolution
linear barcode 0.127 mm (5.0 mil)
2D matrix code 0.169 mm (6.7 mil)
