Installation and Connections
MATRIX CUBE - 11 -
DIAPERFEEDER IP54 Device Technical Characteristics
Power supply voltage 24 VDC ± 10%
0.2 A (during normal operation);
1 A (under stress);
Maximum absorption
3 A (at start-up)
STOP Outputs: relay contacts (NO)
0.3 A 125 VAC
1 A 30 VDC
Opto-insulated Inputs
0-24 VDC
V
IL
Max 1,2 VDC
V
IH
Min 5 VDC
Programmable yarn tension (100g version
0.5 ÷ 100 gr. (resolution 0.1 gr.)
Programmable yarn tension (1000g
version
5 ÷ 1000 gr. (resolution 1 gr.)
Programmable alarms 0.1 ÷ 25 sec.
Dimensions 220 x 86 x 98 mm
Operating temperature range 10° - 60 °C
Storage temperature -25° - +85° C
Tension range 0 / full scale
IP degree IP54
TS44.. Sensor (DIAPER FEEDER) Technical Characteristics
Power supply voltage 12 .. 24 Vdc ± 10%
Absorption 20 mA (max)
Analogue Output 100 mV - 10V
Analogue output resistance 1K Ohm
Operating temperature range 10° - 50 °C
Storage temperature -25° - +85° C
Tension range 0 - full scale
Useful tension range 0% - 95% full scale
Max applicable tension 10 times the full scale value
Drift error 0.05% / °C
Repeatability error 0.5%
Max linearity error 2% (0 - full scale)
Signaling With integrated LEDs
Dimensions 50 x 25 x 12.5 mm
