Installation and Connections
MATRIX CUBE - 12 -
IS3.. Sensor (spool change detection) Technical Characteristics
Power supply voltage 12 .. 24 Vdc ± 20%
Absorption 15 mA (max 20 mA)
STOP output NPN
STOP output protection
Protection against over-voltages/short-
circuits
Maximum Current of STOP output 200 mA continuous; 500 mA pick
Reaction Delay Programmable from 5 to 1000 msec
Sensitivity Programmable (10 levels)
Signaling With integrated LEDs
Dimensions (mm) 25 x 10 x 36.3
Operating temperature range 10° - 60 °C
Storage temperature -25° - +85° C
TS55 Sensor Technical Characteristics
Power supply voltage 12 .. 24 Vdc ± 10%
Absorption 20 mA (max)
Operating temperature range 10° - 50 °C
Storage temperature -25° - +85° C
Tension range 0 - full scale
Useful tension range 0% - 95% full scale
Max applicable tension 10 times the full scale value
Drift error 0.05% / °C
Repeatability error 0.5%
Max linearity error 2% (0 - full scale)
