Installation and Connections
MATRIX CUBE - 18 -
3) Thread the tail of spool 2 on yarn braking device (F1)
4) Connect the head of spool 2 with the tail of spool 1 (knot)
Yarn braking
device (F1)
Spool 1
Spool 2
