Installation and Connections
MATRIX CUBE - 19 -
5) Load spools 3 and 4 on spool holder (B)
6) Connect the head of spool 4 with the tail of spool 3 (knot).
Spool holder
(B)
Spool 3
Spool 4
Spool 4
Spool 3
