2002 Buell X1: Fuel System 4-23
HOME
Test4.10
Set engine stop switch to OFF.
Disconnect ECM connector [10] and
connect Breakout Box.
Turn ignition key switch ON. Jumper
Breakout Box (BK) Pin 4 to ground.
Check engine lamp should be ON. Is it?
Turn ignition key switch ON. Set engine stop
switch to RUN. Does the engine start?
YES
NO
1
Did check engine lamp and no start
conditions occur simultaneously?
YES
No ECM power.
Refer to
4.13 NO
ECM POWER
.
NO
Refer to 4.12 ENGINE
CRANKS BUT WILL
NOT START
for no start
condition and then return
to
4.10 CHECK ENGINE
LAMP NOT ILLUMI-
NATED AT KEY ON
to
resolve no engine
check lamp.
YES NO
Disconnect instruments connector [39].
Remove BK/Y wire from connector [39] and
ground it. Reconnect connector [39].
Check engine lamp ON?
YES
Repair open or
short to voltage on
BK/Y wire between
connector [39] and
connector [10B].
NO
Repair open on O
wire that feeds bulb
or open on wire
from bulb to con-
nector [39].
2
3
Replace ECM. See
4.29 ELECTRONIC
CONTROL MODULE
.
Check bulb.
Bulb OK?
YES NO
Replace
bulb.
