4-96 2002 Buell X1: Fuel System
HOME
OXYGEN SENSOR 4.32
GENERAL
The oxygen sensor (O2 Sensor), located in the header pipe,
monitors oxygen gas content in the exhaust and converts it to
a voltage reading. This voltage reading is used by the ECM to
maintain the proper air/fuel ratio during closed loop operation.
REMOVAL
1. See
Figure 4-79. Unplug 1-place connector [137] under
battery tray.
2. Remove oxygen sensor from exhaust header using a 22
mm (or 7/8 in.) crow’s foot or flare nut socket.
INSTALLATION
1. Apply LOCTITE ANTI-SEIZE LUBRICANT to threads of
sensor. Make sure anti-seize is marked as safe for use
with O2 sensors.
2. See
Figure 4-79. Thread sensor into exhaust header.
Tighten sensor to 42-45 ft-lbs (57-61 Nm).
3. Connect 1-place connector [137] to wiring harness.
Figure 4-79. Installed Oxygen Sensor
7102
Oxygen Sensor
Wire to [137]
Battery Tray
