4-54 2002 Buell X1: Fuel System
HOME
TROUBLE CODE 14 4.19
GENERAL
Engine Temperature Sensor
CAUTION
Do not pull on engine temperature sensor wiring. Excess
strain to sensor wiring will cause sensor damage.
The ECM supplies and monitors a 0-5 volt signal to one side
of the engine temperature sensor (ET sensor). The other side
of the ET sensor is connected to ground through the engine.
See
Ta b l e 4-16. The ET sensor is a thermistor device which
means that at a specific temperature it will have a specific
resistance across its terminals. As this resistance varies, so
does the supplied voltage.
● At high temperatures, the resistance of the sensor is
very low. This effectively lowers the signal voltage.
● At low temperatures, the resistance is very high, allowing
the voltage to rise close to the supplied voltage of 5 volts.
The ECM monitors this voltage to compensate for various
operating conditions.
DIAGNOSTICS
DiagnosticTips
The Scanalyzer displays engine temperature in degrees.
Once the engine is started, the temperature should rise
steadily.
An intermittent may be caused by poor connection, rubbed
through wire insulation or a wire broken inside the insulation.
Check the following conditions:
● Poor connection. Inspect ECM harness connector [11]
for backed out terminals, improper mating, broken locks,
improperly formed or damaged terminals, poor terminal-
to-wire connection and damaged harness.
● Shifted sensor. The temperature-to-resistance values
table may be used to test the ET sensor at various tem-
perature levels in order to evaluate the possibility of a
shifted (out-of-calibration) sensor which may result in
driveability problems.
Diagnostic Notes
The reference numbers below correlate with the circled num-
bers on the Code 14 flow charts.
1. Connect BREAKOUT BOX (Part No. HD-42682) to ECM.
See 4.7 BREAKOUT BOX.
2. Use HARNESS CONNECTOR TEST KIT (Part No. HD-
41404), gray pin probes and patch cord.
Scanalyzer Notes
The Scanalyzer icon appears at those points in the flow chart
where the Scanalyzer can be used.
NOTE
All voltage and resistance values are approximate (+/- 20%).
Engine temperature sensor is measured between Terminal 9
of connector [11] and system ground (Terminals 2 and 11 of
connector [10]).
Table 4-16. Engine Temperature
Sensor Specifications
VOLTS RESISTANCE TEMP °C TEMP °F
0.00 0 300 572
0.21 145 255 491
0.42 303 210 410
0.62 463 190 374
0.81 638 170 338
1.20 1042 150 302
1.59 1539 130 266
3.01 4991 85 185
4.43 25,647 40 104
4.63 41,295 25 77
4.83 93,759 10 50
4.88 134,200 0 32
4.93 232,414 -10 14
