2002 Buell X1: Electric Starter 5-1
HOME
SPECIFICATIONS 5.1
TORQUE VALUES
STARTER
Free Speed 3000 RPM (min.) @ 11.5 V
Free Current 90 amp (max.) @ 11.5 V
Stall Current 400 amp (max.) @ 2.4 V
Stall Torque 8 ft-lbs (11 Nm) (min.) @ 2.4 V
SERVICE
WEAR LIMITS
IN. MM
Brush Length (minimum) 0.433 11.0
Commutator Diameter
(minimum)
1.141 28.981
ITEM TORQUE NOTES
Battery Terminal Hardware 60-96 in-lbs 7-11 Nm page 5-18
Starter Battery Positive Cable Nut 60-85 in-lbs 7-10 Nm metric, page 5-18
Starter Mounting Bolts 13-20 ft-lbs 18-27 Nm page 5-18
