7-2 2002 Buell X1: Electrical
HOME
TORQUE VALUES
ITEM TORQUE NOTES
Battery (+) to Starter Nut 60-85 in-lbs 7-10 Nm (metric), page 7-25
Battery Strap Locknut 40 in-lbs 4.5 Nm page 7-29
Battery Terminal Bolts 60-96 in-lbs 7-11 Nm (metric), page 7-24
Dash Panel Mounting Screws 4-5 ft-lbs 5-7 Nm page 7-42
Dash Panel Screws 4-5 ft-lbs 5-7 Nm page 7-44
Handlebar Control Housing Screws
(left side)
25-33 in-lbs 3-4 Nm page 7-38
Handlebar Control Housing Screws
(right side)
12-17 in-lbs 1-2 Nm longer screw on bottom, page 7-38
Headlamp Housing Screws 6-8 ft-lbs 8-11 Nm metric, page 7-32
Neutral Indicator Switch 3-5 ft-lbs 4-7 Nm
LOCTITE THREADLOCKER 243 (blue), page
7-53
Rotor Mounting Bolts 90-110 in-lbs 10-12 Nm
LOCTITE THREADLOCKER 243 (blue), page
7-22
Spark Plugs 11-18 ft-lbs 15-24 Nm page 7-1
Stator TORX Mounting Screws 30-40 in-lbs 3-4 Nm
T- 27 TORX with retaining compound, replace
with new after each removal, page 7-22
Tu rn Signal Nut (Rear) 96-120 in-lbs 11-14 Nm page 7-35
Tu rn Signal Screws (Front) 25-28 in-lbs 2.8-3.2 Nm page 7-34
Voltage Regulator Mounting Screws 9-11 ft-lbs 12-15 Nm page 7-23
