2002 Buell X1: Chassis 2-3
HOME
Rear Brake Caliper Bleeder Valve 3-5 ft-lbs 4-7 Nm metric, page 2-28
Rear Brake Caliper Mounting Screw,
Large
18-22 ft-lbs 24-30 Nm
LOCTITE THREADLOCKER 272 (red) metric, page
2-32
Rear Brake Caliper Mounting Screw,
Small
14.5-18 ft-lbs 20-24 Nm
LOCTITE THREADLOCKER 272 (red) metric, page
2-32
Rear Brake Caliper Pad Hanger Pin 11-14.5 ft-lbs 15-20 Nm metric, page 2-32
Rear Brake Caliper Pin Plug 1.5-2.1 ft-lbs 2-3 Nm page 2-32
Rear Brake Lamp Switch 84-96 in-lbs 10-11 Nm LOCTITE PST, page 2-35
Rear Brake Master Cylinder Mount-
ing Screws
8-10 ft-lbs 11-14 Nm LOCTITE THREADLOCKER 243 (blue), page 2-51
Rear Brake Pedal Locknut 7-9 ft-lbs 10-12 Nm page 2-51
Rear Brake Reservoir Mounting
Screw
12-15 in-lbs 1.4-1.7 Nm page 2-29
Rear Brake Rotor Screws 35-40 ft-lbs 48-54 Nm
LOCTITE THREADLOCKER 272 (red), metric,
page 2-12
Rear Inner Fender TORX Screw 72-96 in-lbs 8-11 Nm page 2-35
Rear Isolator TORX Bolts 63-70 ft-lbs 85-95 Nm
LOCTITE THREADLOCKER 272 (red) and ANTI-
SEIZE, Special Procedure, page 2-51
Rear Master Cylinder Banjo Bolt 16-20 ft-lbs 22-27 Nm metric, page 2-29
Rear Master Cylinder Mounting
Screws
8-10 ft-lbs 11-14 Nm
LOCTITE THREADLOCKER 243 (blue), metric,
page 2-29
Rear Shock Front Allen Screw 40-45 ft-lbs 54-61 Nm page 2-53
Rear Shock, Rear Bolt 30-33 ft-lbs 41-45 Nm metric, page 2-48
Seat Lock Nuts 20-25 in-lbs 2-3 Nm page 2-80
Shift Lever Bolt 27-29 ft-lbs 37-39 Nm page 2-74
Side Plate Mounting Screws 16-19 ft-lbs 22-26 Nm page 2-51
Sprocket Bolts 55-65 ft-lbs 75-88 Nm LOCTITE THREADLOCKER 272 (red), page 2-12
Sprocket Cover Mounting Screws 12-17 in-lbs 1-2 Nm
LOCTITE THREADLOCKER 222 (purple), page 2-
70
Sprocket Cover Screw 48-72
in-lbs 5-9 Nm LOCTITE THREADLOCKER 243 (blue), page 2-70
Swingarm Isolator TORX Bolts 63-70 ft-lbs 85-95 Nm
LOCTITE THREADLOCKER 271 (red) and ANTI-
SEIZE under bolt head, Special Procedure, page
2-48
Swingarm Pinch Screw 18-20 ft-lbs 24-27 Nm LOCTITE THREADLOCKER 243 (blue), page 2-47
Swingarm Threaded Rod 10-13 ft-lbs 14-18 Nm
LOCTITE THREADLOCKER 222 (purple), initial
torque only, page 2-47
Swingarm/Drive Support Bolts 9-10 ft-lbs 12-14 Nm LOCTITE THREADLOCKER 243 (blue), page 2-70
Ta il Section Bolts 9-11 ft-lbs 12-15 Nm page 2-80
Tie Bar Bolts 30-33 ft-lbs 41-45 Nm page 2-51
Tu rn Signal Nuts 96-120 in-lbs 11-14 Nm metric, page 2-80
Valve Stem Nut 42-44
in-lbs 4.7-5.0 Nm page 2-16
ITEM TORQUE NOTES
