Option: Maximum stroke limitation

Insert threaded nipple → ① into actuator cover ⑥.

 ⑤
Insert o-ring • ⑤ carefully.
Do not use sharp objects. •
Place disk
→ ⑧ inside the actuator cover ⑥.
Fix actuator
→ ⑥ cover with nut ④ on the threaded nipple ①
• Use flats on tube for wrench (WAF24)
• Max. tightening torque: 20 Nm.
Secure nut
→ ④ with Loctite 274.
Assemble actuator cover
→ ⑥ with special wrench
• Max. tightening: G-100 = 45 Nm / H-125 = 60 Nm.
Set max. stroke by adjusting the setscrew
→ ②.
Secure setscrew
→ ② with nut ③.
Test valve for function and leaktightness.
→
