Technical data
6.4 Type label
6.4.1 Type label standard
8691 büS
single act pilot 3,0
Pmax 7bar
Tamb -10 - +55°C Rev. 2
Ser.-Nr. 001000
00179024
D-74653 Ingelfingen
W14UN
Order number, manufacture code
Operatingvoltageoreldbuscontrol
Max. operating pressure
Type
Control function, pilot valve
Barcode
Serial number, CE marking
Ambient temperature, version
Figure 4: Type label standard (example)
6.4.2 UL type label
8691 -E3-...-0
single act pilot 3,0 24V
Pmax 7bar
Tamb -10 - +55°C Rev. 2
Ser.-Nr. 001000
00179024
D-74653 Ingelfingen
W14UN
Order number, manufacture code
Features of the type code applicable to UL and ATEX
Max. operating pressure
Type
Control function, pilot valve,
supply voltage pilot valve
Barcode
Serial number, CE marking
Ambient temperature, version
Figure 5: UL type label (example)
6.4.3 UL additional label
Type 4X enclosure
NEC Class 2 only
Supply voltage: 24 V
Supply voltage device
Circuit with limited power
Degree of protection
Figure 6: UL additional label (example)
