Deinstallation
13.2 Deinstallation
Pilot air port
Exhaust air port
Body casing
Fastening screws
Pneumatic
connection
Actuator
Circular plug-in
connector
External pilot air
duct (Classic)
Integrated pilot air duct (Element)
Basic housing
Figure 41: Deinstalling the device
Pneumatically deinstalling the device
→ Disconnect pilot air port.
→ When exhaust air port connected: Disconnect exhaust air port:
→ With external control air duct (Classic):
Disconnect the pneumatic connection to the actuator.
Electrically deinstalling the device
Devices with circular plug-in connector:
→ Disconnect the circular plug.
Mechanically deinstalling the device
→ Release the fastening screws.
→ Pullothedevicebyliftingupward.
