Burkert 8691 - 0 X2 C0 E Diagnostics

48
Start-up
10.3.5.10 0x2C0E Diagnostics
Sub-
index
Name Description
Access type Data type Data memory
Factory
reset
0x1 Travel accumulator
Travel accumulator total:
Travel distance of the valve spindle from
factory default is added up to determine
the service life.
RO FLOAT32
0x2 Travel accumulator
resettable
Travel accumulator resettable:
Travel distance of the valve spindle is
added up since last reset (e.g. once
maintenance is complete)
RO FLOAT32
0x3 Travel accumulator
limit
Travel accumulator: Activate or deac-
tivate maintenance threshold
0: Diagnostics deactivated
>0: Diagnostics activated
Warning is output when the reset-
table travel accumulator reaches this
threshold
RW Float32T x x
0x4 Valve cycles
Total number of switching cycles:
Number of all ON/OFF switching cycles
performed since factory default
RO UINT32
0x5 Valve cycles
Number of resettable switching cycles:
Number of all ON/OFF switching cycles
performed since last reset.
RO UINT32
0x6 Valve cycle limit
Switching cycles: Activate or deactivate
maintenance threshold
0: Diagnostics deactivated
>0: Diagnostics activated
Warning is output when the number
of resettable switching cycles
reaches this threshold
RW UINT32 x x
0x7 Operating time
resettable
Operating time counter [s] resettable:
Sum of the time for which the device was
receiving an operating voltage.
RO UINT32
0x8 Operating time limit
Operating time counter: Activate or deac-
tivate maintenance threshold
0: Diagnostics deactivated
>0: Diagnostics activated
Warning is output when the reset-
table operating time counter reaches
this threshold
RW UINT32 x x
english
Type 8691, Rev. 2
