Start-up
10.3.5.12 IO-Link-Events
Message Description IO-Link
event code
IO-Link
event type
Action
Internal error Internal device error 0x1000 ERROR Contact Bürkert Service
Internal error: WMS
signal error
Data from WMS
defective
0x1800 ERROR Restart device
If fault persists,
contact Bürkert Service
IO-Link error IO-Link bus error 0x1801 ERROR Check IO-Link connection
Tolerance bands
overlap
Tolerance bands for the
upper and lower position
overlap
0x1802 WARNING Check whether the teach
function has been successfully
performed.
Check whether the tolerance
bands have been correctly con-
gured(totalofbothtolerance
bands should be greater than
the calculated stroke)
Teach function
required
No teach function
present
0x1803 WARNING Starting teach function
Teach function
active
Teach function running 0x1804 WARNING Wait until teach function has
been completed
Teach function
error
Teach function error 0x1805 ERROR Check pilot pressure
Check pilot valve
Restart teach function
If fault persists,
contact Bürkert Service
büS error Communication error 0x1806 ERROR Check signal to büS partner
Check büS network
Check büS producer
Travel limit
exceeded
Speciedtraveldistance
exceeded
0x1807 WARNING Where appropriate, check wear-
and-tear parts in pneumatic
actuator and valve
Switching cycle
limit exceeded
Speciedswitchingcycle
limit exceeded
0x1808 WARNING Where appropriate, check wear-
and-tear parts in pneumatic
actuator and valve
Operating time limit
exceeded
Speciedoperatingtime
limit exceeded
0x1809 WARNING Perform maintenance as
appropriate
Closing time
threshold exceeded
Speciedclosingtime
and tolerance exceeded
0x180A WARNING 1. Check compressed air supply
2. Check actuator and valve for
friction
Opening time
threshold exceeded
Speciedopeningtime
and tolerance exceeded
0x180B WARNING 1. Check compressed air supply
2. Check actuator and valve for
friction
Switching timeout End position not reached 0x180C ERROR Check pilot pressure
Check pilot valve
Restart teach function
If fault persists,
contact Bürkert Service
