10.3.5.6 0x2C01 LED color for end positions
Sub-
index
Name Description
Access type Data type Data memory
Factory
reset
0x1 Color valve opened
LED color for valve open:
Select top LED color for valve in open
position
0:O
1: White
2: Green
3: Blue
4: Yellow
5: Orange
6: Red
RW UINT8 x x
0x2 Color valve closed
LED color for valve closed:
Select top LED color for valve in closed
position
0=O
1 = White
2 = Green
3 = Blue
4 = Yellow
5 = Orange
6 = Red
RW UINT8 x x
0x3
Colorvalvebetween
LED color for valve in-between:
Select top LED color for valve position
between closed and open
0:O
1: White
2: Green
3: Blue
4: Yellow
5: Orange
6: Red
RW UINT8 x x
Table 14: 0x2C01 LED color for end positions
10.3.5.7 0x2C0B Control head settings
Sub-
index
Name Description
Access type Data type Data memory
Factory
reset
0x1 Upper tolerance band
Tolerance band for the upper end
position (open) in mm
RW FLOAT32 x x
