45
Start-up
Sub-
index
Name Description
Access type Data type Data memory
Factory
reset
0x2 Lower tolerance band
Tolerance band for the lower end position
(closed) in mm
RW FLOAT32 x x
0x3 Inverting CMD
setpoint
Invert CMD set-point value
0 = CMD set-point value inversion inactive
1 = CMD set-point value inversion active
RW UINT8 x x
0x4 Opening time (CMD)
Opening time:
Time needed to reach the upper tol-
eranceband,speciedinms.The
message begins when the CMD set-point
value is changed
RO UINT16
0x5 Closing time (CMD)
Closing time:
Time needed to reach the lower tolerance
band,speciedinms.Themessage
begins when the CMD set-point value is
changed
RO UINT16
0x8 Set-point error
Select reaction in the event of a set-point
error (bus error or invalid process data)
0 = Maintain position
1=Safetyposition(pilotvalveo)
RW UINT8 x x
0xA Moving direction
Direction of valve movement
-1: Valve leaves upper end position
(Movement downwards)
0: Valve is in end position
1: Valve leaves lower end position
(Movement upwards)
RO SINT8
0xC Device lock
Activate or deactivate local operation:
Button for manual operation inside the
device is deactivated to prevent uninten-
tional operation
0 = Not deactivated (button is enabled)
1 = Deactivated (button is disabled)
RW UINT8 x x
0xE Opening time
Opening time:
Time, measured from the time when
the lower tolerance band is left until the
time when the upper tolerance band is
reached,speciedinms
RO UINT16
0xF Closing time
Closing time:
Time, measured from the time when
the upper tolerance band is left until the
time when the lower tolerance band is
reached,speciedinms
RO UINT16
Table 15: 0x2C0B Control head settings
english
Type 8691, Rev. 2
